Metal Ring Nema 14 Geared Planetary Gearbox Stepper Motor With Reducer 1.0A L 28/39mm 200/250mN.m

Product Categories

Chongqing Umot Technology Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: Metal Ring Nema 14 Geared Planetary Gearbox Stepper Motor With Reducer 10A L 2839mm 200250mNm
Brand: Umot
Price: 31.69 USD

Warranty : 1 year

Place of Origin : Chongqing, China

Brand Name : Umot

Model Number : 35HSH2408/5401

Phase : 2

Type : Hybrid

Current / Phase : 1A

Product name : Nema 14 Geared Stepper Motor

Motor length : 35x28mm/35x39mm

Ring material : Metal

Current : 1A

Number of gear trains : 1-4

Bearing at output : Ball bearings

Gearbox torque : 0.668-6N.m

Holding torque : 200m.Nm/250m.Nm

Efficiency : 66-90%

Reduction ratio : 3.7:1/5.2:1/14:1/19:1/27:1/51:1/71:1/100:1/139:1

MOQ : 5 pieces

Price : $31.69/pieces 5-99 pieces

Contact Now

35mm Geared Planetary Gear Motors Nema 14 Micro Geared Stepper Motor With Reducer Gearbox

Item	Value
Product name	Nema14 35mm Planetary gearbox stepper motor
Warranty	3months-1year
Place of Origin	China
Brand Name	Umot
Model Number	35HSH2408/35HSH5401
Phase	2 Phase
Type	Hybrid
Rated Current	1.0A
Holding Torque	200/250mN.m
Certification	CCC, ce, RoHS
Step angle	1.8°
Rated voltage	4.5V
Weight	0.15/0.25kg
Motor length	35mmx28mm/35mmx39mm
Load range	1.8N.m-6.0N.m
Efficiency	66%-90%

Metal Ring Nema 14 Geared Planetary Gearbox Stepper Motor With Reducer 1.0A L 28/39mm 200/250mN.m Images
